Godox Studio Lighting | AD200Pro TTL Pocket Flash

AT A GLANCE

• 1 x Speedlite, 1 x Bare Bulb Flash Heads
• 1 x Lithium Battery, 1 x Charger
• Built-In Wireless X System Receiver
• HSS: 1/8000 sec, Battery: 500 FP Flashes
• Optional X1 Wireless TTL Transmitter
• Supports Nikon, Canon, Sony TTL
• Supports Olympus, FUJIFILM TTL
• Flash Exposure Compensation
• TTL, Manual, and Stroboscopic Modes
• Firmware USB Updates, 1 x Carry Case

DESCRIPTION

An enhanced version of its predecessor, the AD200Pro TTL Pocket Flash Kit from Godox is built around a unique flash source with a standard speedlight head and a bare bulb head that give you the option of two distinctly different qualities of light. The kit comes with the two heads, lithium battery, charger, and carry case.

The speedlight head outputs the standard look of an on-camera flash that can be modified using an optional softbox, beauty dish, or umbrella. The bare bulb head features a removable flash tube and produces 360 degrees of soft, bright, nearly shadowless light. The head uses optional reflectors that focus the beam angle and give you directional control. The AD200Pro has impressive core features such as 200Ws of power adjustable in 9 steps from 1/256 to 1/1, recycling from 0.01 to 2.1 seconds, and flash durations as short as 1/15,380 sec. The flash runs on a removal, rechargeable lithium battery that will give you up to 500 full power flashes and thousands of lower power flashes.

The AD200Pro has 3 flash modes: Manual, TTL, and Multi (Stroboscopic). Manual outputs the user’s choice of power, modeling light, first or second curtain sync, etc. Multi controls the stroboscopic rate up to 90 times (90 Hz). TTL takes advantage of the flash head’s built-in X1 receiver. Optional X1 TTL transmitters are available for Nikon, Canon, Sony, Olympus, and FUJIFILM cameras. They will also detect a separately purchased LED head. The 32-channel wireless system controls flash mode, first and second curtain sync, High-Speed Sync up to 1/8000 second, power level, modeling lamp, and ready beeper at distances up to 328′. Firmware updates are obtainable on the Godox website.

Built-In 2.4 GHz Wireless X System
Built-in wireless receiver: control triggering power level, alert beep with optional wireless transmitter. Compatible with Nikon, Canon, Sony, Olympus, Panasonic and Fuji TTL.

Bare Bulb and Speedlight Flash Heads
Bare bulb and speedlite flash heads are included to vary your quality of light. Color temperature is a steady 5600K over the entire power range.

Large Capacity Lithium Battery Pack
The 14.4 V / 2900 mAH battery pack gets 500 full power flashes with 0.01 to 2.1 sec. recycling.

AV Panel
Easily readable digital panel displays your adjustments

Accessories
Barn Doors, color filters and diffusers are available to personalize your work.

Numerous Control Functions

• 9-Step Power Range: 1/1 to 1/256
• Supports flash exposure compensation
• 1/8000 sec high-speed Sync
• First and second curtain sync
• Modeling lamp
• Manual flash
• Multi flash
• Custom functions

SPECIFICATIONS

Maximum Watt/Seconds 200
Compatibility

• TTL with Canon, Nikon, Sony cameras with optional X1-C, X1-N, and X1-S transmitters
• TTL with Olympus/Panasonic, Fuji cameras with optional X1T-O and X1T-F transmitters

Control

• Manually on unit
• Via X1 Transmitter Which Will Wirelessly Control:
• Flash Mode: TTL, Manual, Multi (Stroboscopic), power level
• Modeling lamp on/off, Beeper on/off
• First and second curtain sync, High Speed Sync

Guide Number
At Full Power

• Speedlite Flash Head: 170.6′ (52 m) ISO 100 @ 35 mm
• Bare Bulb Flash Head: 197′ (60 m) ISO 100 with AD-S2 reflector @ 28 mm
• Colour Temperature 5600K (+/-200K)
  Recycle Time 0.01 to 2.1 sec
  Flash Duration
  Speedlite Flash Head at t0.1: 1/220 to 1/15,380 sec
  Bare Bulb Flash Head at t0.1: 1/220 to 1/13,510 sec
  Flash Variability 9 Steps: 1/256 to 1/1
  Flash Delay Yes, 0.01 to 30 sec
  Flash Modes
  TTL, Manual, Multi (Stroboscopic)
  Stroboscopic: up to 90 times (99 Hz)
  Modeling Light Uses Speedlite Head: Auto turn off after 30 minutes
  Sync Mode
  High-speed sync up to 1/8000 sec
  First curtain sync and second curtain sync
  Flash Exposure Compensation Yes, plus or minus 3 stops in 1/3 stop increments
  Flash Ready Indicator
  LED, beep
  Flash hibernates automatically after 30 minutes of non-use
  Built-in Slave Cell
  S1 and S2 optical slave modes
  2.4 GHz radio system
  Wireless & Radio Specifications
  Function: Slave or Off
  Channels: 32
  Groups: 5 (A, B, C, D, E)
  Range: 328′ (100 m)
  Mounting
  1/4″-20 female threads
  AD-E Holder (stand mount)
  Fan Cooled No
  Replaceable Flashtube Yes, in bare bulb head
  Connectors
  3.5 mm sync input
  Wireless control port
  USB port
  Battery
  Lithium, 14.4 V / 2900 mAH
  Power remaining indicator
  Number of Flashes @ Full Power 500
  Dimensions 6.7 x 3.0 x 2.0″ / 172 x 75 x 54 mm Without Flash Head
  Weight 20.8 oz / 590 g Without Flash Head and Battery
  Package Weight 4.225 lb
  Box Dimensions (LxWxH) 9.9 x 7.5 x 3.9″

Godox AD200Pro TTL Pocket Flash Kit
• Godox H200 Speedlite Flash Head
• Bare Bulb Flash Head
• Flash Tube
• Godox Lithium-Ion Battery Pack for AD200 Pocket Flash (14.4V, 2900mAh)
• Charger and Cable
• Bracket
• Carrying Case
