Nikon Telephoto Zoom | 200-500mm f5.6 E ED VR AF-S Lens

AT A GLANCE

• F Mount Lens/FX Format
• Aperture Range: f/5.6 to f/32
• Three Extra-Low Dispersion Elements
• Super Integrated Coating
• Silent Wave Motor AF System
• Vibration Reduction with Sport Mode
• Internal Focus, Manual Focus Override
• Electromagnetic Diaphragm Mechanism
• Detachable, Rotatable Tripod Collar
• Rounded 9-Blade Diaphragm
• Filter Thread Front: 95 mm x 1.0 mm Pitch

DESCRIPTION

Spanning a long, versatile zoom range, the AF-S NIKKOR 200-500mm f/5.6E ED VR Lens from Nikon is a telephoto zoom characterized by a constant f/5.6 maximum aperture for consistent performance throughout the zoom range. The optical design incorporates three extra-low dispersion glass elements to reduce chromatic aberrations and distortions for increased sharpness and colour accuracy. Also contributing to improved image quality,a Super Integrated Coating has been applied to lens elements to lessen flare and ghosting for improved contrast and clarity.

A Silent Wave Motor AF system produces fast, near-silent focusing performance that suits both stills shooting and movie recording which can instantly be manually overridden by simply turning the manual focus ring. Further contributing to photographing in fast-paced situations and difficult lighting, VR (Vibration Reduction) image stabilization compensates for the effects of camera shake by up to 4.5 shutter speed stops. Additionally, an electromagnetic aperture mechanism is integrated into the lens design to provide greater exposure control stability that is especially beneficial when working with faster continuous shooting rates.

• Designed for use with FX image sensors, this lens is also compatible with DX sensors where it will provide a 300-750mm equivalent focal length range.
• Constant f/5.6 maximum aperture offers consistent performance throughout the zoom range.
• Three extra-low dispersion glass elements work to reduce chromatic aberrations; improve overall image sharpness, clarity, and color fidelity; and help to minimize the overall weight of the lens.
• A Super Integrated Coating has been applied to lens elements to minimize surface and internal reflections for a marked reduction in lens flare and ghosting.
• Vibration Reduction image stabilization helps to reduce the appearance of camera shake for up to 4.5 shutter speed stops, benefiting this lens’ use in low-light conditions. Additionally, a designated Sport Mode is well-suited to working in fast-paced conditions where panning and other lateral camera movements are more common.
• Silent Wave Motor autofocus mechanism provides quick, quiet, and precise autofocus performance that is ideal for photographing fast-moving subjects.
• Full-time manual focus override allows instant switching between AF and MF focusing systems by just rotating the focus ring at any time.
• Internal focusing design maintains the overall lens length during operation and contributes to a lighter overall weight, as well as a minimum focusing distance of 7.2′.
• Specialized electromagnetic aperture mechanism provides greater exposure control stability that is especially beneficial when working with fast continuous shooting rates.
• This mechanism limits the compatibility of this lens to the following cameras: D4 series, D3 series, Df, D810, D810A, D800 series, D750, D700, D610, D600, D300 series, D7200, D7100, D7000, D5500, D5300, D5200, D5100, D5000, D3300, D3200, D3100, Nikon 1 J1, J2, J3, J4 with FT-1, Nikon 1 V1, V2, V3 with FT-1, and Nikon 1 S1, S2 with FT-1.
• A rotating tripod collar offers well-balanced support for photographing atop a tripod or monopod with either vertical or horizontal shooting orientations.

SPECIFICATIONS

Focal Length 200 – 500mm
Aperture Maximum: f/5.6 Minimum: f/32
Camera Mount Type Nikon F
Format Compatibility Nikon FX/35mm Film
Angle of View 12° 20′ – 5°
Minimum Focus Distance 7.2′ (2.19 m)
Magnification 0.22x
Elements/Groups 19/12
Diaphragm Blades 9, Rounded
Image Stabilization Yes
Autofocus Yes
Tripod Collar Yes Removable – rotating
Filter Thread Front: 95 mm x 1.0 mm Pitch
Dimensions (DxL) Approx. 4.25 x 10.53″ (108 x 267.5 mm)
Weight 4.60 lb (2090 g)

Nikon AF-S NIKKOR 200-500mm f/5.6E ED VR Lens
• 95mm Snap-On Lens Cap
• LF-4 Rear Lens Cap
• HB-71 Bayonet Lens Hood
• CL-1434 Semi-Soft Lens Case
• Tripod Collar
